Unvented Cylinders

What is an unvented cylinder and why go mains pressure?

An unvented cylinder is a sealed hot water store fed directly from the cold main, so hot water leaves it at mains pressure rather than dribbling down from a loft tank. The result is powerful showers on every floor, fast-filling baths, and no cold water storage in the loft at all.

The old gravity arrangement — cold tank in the loft, vented cylinder in the airing cupboard — delivers pressure based on how far the water falls. A top-floor shower a metre below the tank gets almost nothing, which is why so many gravity homes bolt on noisy pumps. An unvented cylinder replaces all of that with the pressure your street main already provides, typically transforming the shower without any pump at all.

There are two honest caveats. First, performance depends on your incoming main: we measure flow and pressure at the survey, because a poor main needs addressing before a cylinder can shine. Second, unlike a vented system, an unvented cylinder needs its safety components serviced annually — pressure relief valves and the expansion arrangement are what keep a sealed vessel safe, and they only stay reliable if someone competent looks at them once a year.

What are the G3 regulations for unvented cylinders?

UK Building Regulations require every unvented cylinder to be installed by an engineer holding the G3 qualification, the installation to be notified to building control, and the discharge pipework — known as D1 and D2 — to be sized, routed and terminated to strict rules so an over-pressure event vents safely.

The logic is simple: a sealed vessel of hot water under pressure must be able to relieve itself safely if a control fails. That's why an unvented cylinder carries layered protection — a thermostat, a high-limit cut-out, a temperature and pressure relief valve, and an expansion device — and why the D1/D2 discharge pipe that serves those valves has rules about diameter, material, gradient, length and where it can legally terminate. A discharge pipe run in the wrong material or terminating somewhere it could scald someone is a fail, full stop.

What this means for you as a customer: ask any installer two questions — are you G3 qualified, and will building control be notified? We answer yes to both on every job, and you receive the paperwork proving it. That certificate matters beyond safety: solicitors ask for it when you sell, and warranty claims on the cylinder can hinge on documented compliant installation and annual servicing.

What size unvented cylinder does my home need?

As a rule of thumb: 150L suits a one-bathroom home, 210L a home with a bathroom and en-suite, 250L a three-bathroom home, and 300L or more for four-plus bathrooms or homes with large bath-filling habits. Bedrooms matter less than bathrooms — simultaneous showers are what drain a cylinder.

Sizing is a balance. Too small and the third shower of the morning runs cool, which defeats the point of the upgrade. Too large and you pay to heat water nobody uses, day after day — and the cylinder may not physically fit the airing cupboard anyway. We size from how your household actually uses hot water: how many bathrooms, how many people showering in the same hour, whether anyone is a dedicated bath person, and what the boiler can reheat in a reasonable recovery time.

The large detached homes around Esher, Cobham and Oxshott are classic 250–300L territory — four or five bathrooms, often with body-jet showers that drink hot water — and frequently benefit from a faster-reheating system boiler to match. A two-bathroom semi in Molesey or Walton is almost always a 210L. We'll measure, ask the unglamorous questions, and put the recommended size and the reasoning in writing — and if a future heat pump installation is on the cards, we'll specify a heat-pump-ready cylinder now.

What does an unvented cylinder cost installed?

A typical supply-and-fit unvented cylinder installation costs £1,800–£2,800 in this part of Surrey, depending on cylinder size, brand and how much pipework must change. That includes the cylinder, G3-compliant safety and discharge pipework, building-control notification and removal of the old tanks.

Where jobs land in that range: a straight swap of an existing unvented unit sits at the bottom; a conversion from a vented gravity system — new discharge runs, loft tanks decommissioned and removed, pipework rerouted — sits in the middle to upper part; and a large 300L cylinder in an awkward location, or one needing a new reinforced base, tops it. If your incoming main needs upgrading to feed the cylinder properly, we'll quote that separately and honestly rather than hiding it in a provisional sum.

Budget one more line: the annual service — relief valves, expansion vessel, anode — a modest cost that protects the warranty, keeps the safety case sound, and in Surrey's hard water catches scale problems while they're still cheap. We offer it standalone or bundled with your annual boiler servicing.

How does Surrey's hard water affect your cylinder?

Surrey water is very hard — typically over 300 ppm — and hard water attacks cylinders two ways: limescale coats the heating surfaces, slowing reheat and wasting energy, and it accelerates the consumption of the sacrificial anode that protects some cylinders from corrosion. Specification and servicing both need to respect that.

In practice we lean towards stainless steel cylinders, which resist hard water well, and we check the anode arrangement at every annual service on cylinders that use one — an anode is designed to be consumed so the cylinder isn't, but only if someone replaces it before it's gone. On the immersion side, scale shortens element life, so we check elements rather than waiting for the trip to tell you one has died.

Scale protection on the cold feed is worth a conversation on most installations here. An inline scale inhibitor is cheap insurance; a full water softener is a bigger investment that transforms the whole house, not just the cylinder — though softened water and certain cylinder types need pairing correctly, a detail we sort at the survey. We'll recommend what your water and your budget justify, and nothing more.
